Lab Three-Layer Co-extrusion Blown Film Machine

Brand POTOP

Detail

APPLICATION

● New material formulation development

● Material blown film performance test

● Masterbatch dispersion performance test

● Optimization of process parameters for blown film production

● Preparation of a three-layer blown tubular film

● Studying the blown film forming performance of materials

● Studying the dispersion performance of pigments

FEATURES

● Driven by servo motors, stepless precision speed regulation, stable plasticization and good consistency.

● Special gearbox with high-strength servo motor for excellent cooling effect.

● Electric lifting membrane frame, traction roller is cantilever structure, convenient for film leading and process adjustment.

● Equipped with blown film frame expansion device for easy transportation and movement.

● Vector ring, energy-saving, low noise.

● High-strength European-standard integrated rack with aesthetic design. Easy to operate, light and compact.

● 304 stainless steel desktop.

● Computer-based measurement and control system with user-friendly operation interface.

● Real-time measurement and graphic display of important data such as extrusion system, easy to observe.

● Emergency stop device and protective measures for operator's safety.

SPECIFICATION

Model	FBCL-20/03
Applicable Materials	PE/POF/PVC/LDPE/LLDPE etc.
Dia	20mm
L/D	28
Screw Speed	0-120rpm
Max. lay flat width	200mm
Product specification	0.02-0.15mm
Die head width	45mm
Film layer	3
Roller width	220mm
Line speed	0-10m/min
Operating temperature	Room temperature-350°C
Temperature control accuracy	±1℃
Control	SIEMENS PLC
Working voltage	Three-phase 380VAC±10%, single-phase 220VAC±10%,50Hz
Rated power	Approx. 30kW
L×W×H	2810mm×2130mm×2015mm
Weight	Approx.1200kg
